Size | Min Spacing of Wires |
Diameter of Cutting Wire | Outline Dimensions | |||
For Horizontal Cutting(mm) |
For Side Trimming(mm) |
L (mm) |
W (mm) |
H (mm) |
||
4.2*1.2*0.6 | 5mm | Φ0.6-Φ0.8 | Φ0.8 | 5500 | 2860 | 2500 |
4.8*1.2*0.6 | 5mm | Φ0.6-Φ0.8 | Φ0.8 | 5500 | 2860 | 2500 |
6.0*1.2*0.6 | 5mm | Φ0.6-Φ0.8 | Φ0.8 | 6500 | 2860 | 2500 |
Size | Min Spacing of Wires |
Range of Oscillation (mm) |
Diameter of Cutting Wire (mm) |
Outline Dimensions | ||
L (mm) |
W (mm) |
H (mm) |
||||
4.2*1.2*0.6 | 10mm | 7.5 | Φ0.6-Φ1.0 | 5200 | 3200 | 3560 |
4.8*1.2*0.6 | 10mm | 7.5 | Φ0.6-Φ1.0 | 5900 | 3200 | 3560 |
6.0*1.2*0.6 | 10mm | 7.5 | Φ0.6-Φ1.0 | 7200 | 3200 | 3560 |
